Page 104 - Rules of Navigation2020

Width of
Design Channel at
Kilometric Position Designation of
Different Parts of Depth 22.25 m Remarks
(1)
the Channel Depth

From Km. To Km. Meters Meters
Straight line, East
32.350 32.950 encoche of Km. 32 24.00 212 -------
(siding of Km. 32)

Straight line, Southern
32.950 34.862 approach to encoche 24.00 212 – 135 -------
(siding)
34.862 49.512 Straight line 24.00 135 -------

Northern approach to
51.611 West Ballah Zone
49.512 24.00 Variable -------
51.647 East (To West and
East channels)
(E): East Kilometric Base Line.
(3) Double Channel from (Km 51.660 West/Km 51.647 East) to Km 122.100:

3.1 - West Channel from Km 51.660 to Km 122.100:
Table No. 4/3/1

Width of
Designation of Design Channel at
Kilometric Position Different Parts of Depth 22.25 m Remarks
(2)
the Channel Depth
From Km. To Km. Meters Meters
51.660 52.054 Straight line 24.00 135

52.054 53.512 Curve of Km. 53 24.00 Variable

53.512 54.098 Approach to curve 24.00 Variable
Ballah
54.098 56.398 Straight line 24.00 135
West
56.398 56.871 Approach to curve 24.00 Variable Zone
Km. 57
56.871 58.797 Curve of Km. 57 24.00 Variable
Southern approach to
58.797 60.137 Ballah West Zone 24.00 Variable
Junction
60.137 63.419 Curve of Km. 61 24.00 Variable
zone
63.419 64.514 Approach to curve 24.00 169.87 - -------
142.50
64.514 71.164 Straight line 24.00 142.50 -------

1 ) Navigational depth of channel - (See Plans P.NO (118,119)& Cross Sections P.NO (133).
2 ) Navigational depth of west channel - (See Plans P.NO(120,121) & Cross Sections P.NO (134).
