P. 37

a)  Northbound Vessels:
                         1 - All  northbound  vessels  use  the  east  approach channel.  The  end  of the  navigable

                             channel is marked by 2 pairs of buoys at Hm.230, course: 014º from Hm. 230, vessels
                             are to steer North (000º) for 5 miles before altering to destination.

                         2 - Vessels  leaving  Port  Said  harbor  to  sea,  use  the  West  approach  channel  course:
                             037.5º till Hm. 80 (Buoys No. 5) then steer (000º) to 5 miles North of the buoy of
                             Hm. 230 West:

                              Lat.     31º 26’.99 N
                              Long.  32º 24’.40 E

                              before altering to destination.
                          3 - Vessels of the northbound convoys wishing to enter Port Said Harbor may proceed

                              through the west channel (direct to their allocated berth in Port Said Harbor), only
                              If the situation of traffic permits. Otherwise they have to proceed through the east

                              approach channel till Hm. 230, then steer north (000º) for 5 mile and head for the
                                                                                 (1)
                              anchorage berth allocated by the Suez Canal Port office.
                       b)  Southbound Vessels:

                         1. VLCC’s, ULCC’S in ballast or partially loaded, L.P.G. & L.N.G. (Loaded or N.G.F)
                           and vessels having draught more than 42 feet and up to 50 feet maximum, have to use

                           the east approach channel, course:194º. The said vessels enter the channel between FL.
                           Gr. buoy of Hm. 165 and Q. Gr. buoy at Hm. 135. Vessels with draught over 50 ft. and
                           up to 66 ft. must enter the approach channel between FL. Gr. buoy & FL. R. buoy of

                           Hm. 230.
                         2. All other vessels, transiting the Canal or berthing at Port Said have to enter through

                           the West approach channel. Course:180º from the entrance, passing between the West
                           green buoys and the East yellow – green - yellow buoys till Hm. 80, then alter course

                           to 217.5º passing between green and red buoys, till Port Said Harbor.
                           A fixed red light on a pylon on the North Quay of Abbas Basin in line with an occulting

                           red Light on a pylon West of the Fuel Oil Tanks at Raswa, indicates the axis of the
                           entrance channel to the harbor.
                    C - Breakwaters:

                     1. The west approach channel is protected by two breakwaters:
                        a)  The western breakwater protecting the west approach channel is situated to the west of

                           the channel and extends from land boundary till Hm. 73 with a submerged part from
                           Hm. 43. This part is marked by cigar shaped unlit buoys.



                    1  ) This is to avoid crossing to vessels incoming to the northern anchorage area.


                                                            - 13    -
