1-  Port Said “Fairway Buoy”:
                                                         (1)
                              Off Port Said, a fairway light buoy height  10 meter, painted Black with Yellow

                              horizontal stripes, surmounted by a day mark 2 cones point up, and showing Q.
                                        Lat.     31º 21’.32 N

                                        Long.  32º 20’.81 E
                              –  Buoy No. 8 Green Day mark:  Cone point up. F. Gr. Light.
                                        Lat.     31º 21’.13 N

                                        Long.  32º 21’.04 E
                              –  Buoy No. 7 Green Day mark:  Cone point up. F. Gr. Light.

                                        Lat.     31º 20’.52 N
                                        Long.  32º 21’.31 E

                              –  Buoy No. 6 Green Day mark:  Cone point up. F. Gr. Light.
                                        Lat.     31º 19’.91 N

                                        Long.  32º 21’.58 E
                          2-  The west approach channel:
                              Is buoyed as follows:

                              – In the West: Green Day mark:  Cone point up. F. Gr. Light.
                              – In the East:  Red, Day mark:  Can F. R. Light.

                              – Buoy No. 5 of Hm. 80 East Red:  Day mark:  Can F. R.
                                        Lat.     31º 19’.13 N
                                        Long.  32º 22’.11 E

                              – Buoy No.5 of Hm.80 West Green:  Day mark:  Cone F. Gr.
                                        Lat.     31º 19’.30 N

                                        Long.  32º 21’.85 E
                                           (1)
                       d)  El Bahar Tower:
                          The tower is existing at position:
                                 Lat.     31º 18’.090 N
                                 Long.  32º 21’.571 E
                          Shows at night FL. R from the top and 4 white lights from each corner at the base. The
                          tower is fitted with "Fog Horn" and RACON (Q).
                    (2) Navigation:

                       The maximum draught authorized for vessels is limited to 66 feet, on condition to comply
                       with the tables in p. (53 – 57) giving the maximum draught according to the vessel’s beam.





                    1 ) See Drawings Part II.
