BOILERS

          1- Water Tube Boilers :

          Remove access, clean, open up drums and headers for inspection and reclose.
                               Working pressure                   Charges
                                            2
                                    Kg / cm                        U.S.D.
                              Up to         20                      2350
                                       40                           3125
                              Above       40                        3900

          Notes :
             (١)  Manhole gaskets, owner supply.
             (٢)  Chemical cleaning excluded.
             (٣)  Staging 5% extra charge.
             (٤)  Any repairs excluded.
             (٥)  Spreading of water pipes (pipes vessel supply) additional changes will be as following.
                             th
                   st
                 - 1  pipe to 10  pipe        115 U.S.D. / pipe
                         th
                 - From 11  pipe and over     25 U.S.D. / pipe

          II – Boiler Valves :
          * Open up, clean, grind in close up with new packing :
                                  Valve Diam.                     Charges
                                    In Inches                      U.S.D.
                                        1                            80
                                        2                            95
                                        3                           100
                                        4                           140
                                        5                           160
                                        6                           185
                                        7                           210
                                        8                           240

          Notes :
             (١)  Any renewals or repairs are excluded.
             (٢)  Safety valves to be charged as follows :
                 - Single seat   300 U.S.D.
                 - Double seat  450 U.S.D.

          III – CONDENSERS :
          Remove doors, clean up tubes, test, clean doors paint and close up.
                                      Shaft                       Charges
                                  Horse Power                      U.S.D.
                                      5 000                         1100
                                     10 000                         1875
                                     20 000                         2875

          Notes :
             (١)  Any repairs are excluded.
             (٢)  Water for testing extra charge.
