TAIL SHAFTS & PROPELLERS

                                                 AND RUDDERS

          ١- TAIL SHAFTS & PROPELLERS :

                                                         Charges in U.S.D.
        Shaft                                                                                      Simplex
         diam                   Withdraw &                                     Propeller      overhauling with
                   Clearance                        Crack       Stern gland                    owner’s spares
         inch                      refit for                                     Light
                    / Bearing                      inspec.        repack                     Normal type
                                    survey                                     Polishing
                                                                                              including
                                                                                                           Split
                                                                                                shaft
                                                                                             withdrawal
      Up to  8         140           2625            140            280            175         3416       1575
             10        175           3150            175            350            224         4116       1890
            12         266           3500            175            434            266         4550       2100
            13         266           3850            175            434            308         5005       2310
            14         266           4375            175            434            350         5684       2625
            15         350           4900            175            525            385         6370       2940
            16         350           5250            175            525            420         6825       3150
            17         350           6125            175            525            455         7966       3675
            18         434           7000            175            616            490         9100       4200
            19         434           7875            175            616            525         10234      4725
            20         434           8750            175            616            560         11375      5250
            21         490           9625            175            700            595         12516      5775
            22         490          10500            175            700            630         13650      6300
            23         490          11375            175            700            665         14784      6825
            24         525          12250            175            784            700         15925      7350


          Notes :
             (١) Tail shaft or propeller transportation to workshop execluded
             (٢)  For oil lubrication shaft ( excluding CPP ) extra charge 25 %
             (٣) Removal of second intermediate shaft 50% extra charge of Tail shaft withdrawal
             (٤) Gland packing owners supply.
             (٥) C.P.P. to be charged extra 50%.
             (٦) Rope guard removal and refitting, 5% extra charge of tail shaft withdrawal .
             (٧) Over hauling of the oil seal unit excluded.
             (٨)  For in between size the rate of the nearest higher shaft size will apply.
             (٩) Renewal of inner and outer bush excluded.
             (١٠) Extra charge for lignum vitae bush to be 50 U.S.D. per kg.
             (١١) Alignment checks and rectifications excluded.
             (١٢) Repair or machining will be extra charge.
             (١٣) Scaffolding 10 % extra charge if necessary.

                 N.B. :  In case scaffolding are used for more than one job, the extra charge will be based on the
                        highest job cost.
