SEA VALVES & CHESTS


          I- SEA VALVES :

                                      Open up, cleaning, grinding and repack in place :

                                                                      Charges in U.S.D
                        Valve diam. Inch        Globe, angle and non
                                                                           Gate Valves       Butterfly Valves
                                                    return  valves
                        Up to       1                     41                    55                  72
                                2                         55                    68                  86
                                3                         76                    89                 108
                                4                        103                    123                151

                                5                        123                    150                186
                                6                        137                    171                215
                                7                        150                    192                240
                                8                        179                    205                258

                                9                        198                    232                286
                                10                       219                    253                315
                                12                       272                    293                363
                                14                       293                    352                447
                                16                       324                    374                478
                                18                       367                    404                517

                                20                       440                    586                724
                                22                       514                    660                817
                                24                       586                    733                924
                         Above   24                 Per agreement          Per agreement      Per agreement


          Notes :
             (١) Filters will be considered as per the subsequent valves with same size and type .

             (٢) Repair, renewals, sandblasting  and access work excluded .

             (٣) Valves in pump rooms, cofferdams and tanks 30% extra.

             (٤) When valve is removed to shop charges will be increased by 30%.

             (٥) Spare parts owner supply.

             (٦) 50% Reduction of butterfly charge will be applicable in case of cleaning & inspection of butterfly
                 valves through see chests.
