Page 186 - Rules of Navigation2020

Suez Canal Cross Sections

Phase 66'

DW. NO. (26/28 ) __ Page (137)
West 227.00 East

( 00.00 ) m
- ( 9.00 )
3 / 1 3 / 1
- ( 11.00 ) m theoretical reference level
- ( 24.00 ) m
137.00
37.50 - 40.50 215.00 70.00

Cross Section at Km 126.107 - 128.899

West 247.00 East

( 00.00 ) m
- ( 9.00 )
- ( 11.00 ) m theoretical reference level
3 / 1 3 / 1
- ( 24.00 ) m
157.00
75.00 235.00 50.00
Cross Section at Km 129.499 - 131.975 ( Curve )

East
West
217.00
variable
( 00.00 ) m variable
- ( 9.00 )
- ( 11.00 ) m theoretical reference level
3 / 1 3 / 1
- ( 24.00 ) m
127.00
43.00 - 36.00 205.00 47.62 - 46.95 - 46.28

Cross Section at Km 134.543 - 141.875
Cross Section at Km 143.125 - 144.714
