(9) Surface currents (from Surface till one-meter depth) may be affected by wind.
                      (10) Tidal current is not the same over depth. maximum current occurs at most of the time

                         at depth between 6 to 9 meters from surface
                     D-Current Buoys  :

                      In the Canal, there are current buoys indicating the direction of the current  :
                      Head Current : Red & White horizontal bands or 1 reflector at night. Stern Current : Black
                      & White vertical stripes or 2 reflectors at night.

                      These buoys are laid in the following positions  :


                        Port Fouad .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..   Km.   2.750
                        Al Raswa .......................................................  Km.  3.710 East

                        Ras El-Ish( E ) ............................ …………..  Km. 12.800
                        Ras El-Ish(W) ........................ .. .. .. ………..   Km. 14.304

                        EL-Tina .................................. ………….…  Km. 24.775
                        EL-Cap .................................. ……………..   Km. 35.420
                        Kantara .. .. .. .. .. .. .. .. .. .. .. .. .. .. .………..   Km. 45.130

                        Ballah(E&W) ...............................................    Km. 54.770
                        El Ferdan .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..   Km. 64.894

                        Ismailia .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..   Km. 76.133
                        Toussoum .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..  Km. 86.780
                        Deversoir ( E & W ) .. .. .. .. .. .. .. .. .. .. .. .. .  Km. 97.845

                        Kabret ( E & W ) . .. .. .. .. .. .. .. .. .. .. .. .. .. .  Km. 120.827
                        Gineifa.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..  Km. 133.950

                        Shallufa. ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .  Km. 146.125
                        Port Tewfik ...................................................  Km. 160.300


                    Art. 85 - Weather Forecast:

                      Six Meteorological stations are installed on the Canal area. Information about weather will
                      be passed to vessels through pilots by Ismailia Radio station
