          Machine tool workshops :

             - Center lathes : Max job to be
                turned 80 cm dia. 11 m

                length, or 170cm dia. 600

                cm. length.

             - Vertical lathes : Max. job to be

                turned 5.5 m dia, 2.75 m
                height.

             - Crank grinding machine for

                cranks up to 3 m. length.



          Shipbuilding workshops :
            -  Presses up to 700 t .

            -  Frame bending machines up

                to 400 t .
            -  Rolling machines up to 45

                mm. thickness .
            -  Shot blasting and painting

                machine with nominal

                capacity 50 t/hr .
            -  CNC Plasma /oxy –

                Acetylene cutting M/C :

            o  Track width 9700 mm.
            o  Track length 30000 mm.

            o  Cutting width 2x300 mm.

                mirror image mode.
            o   Cutting length 2x12000 mm.

            -  Automatic cutting machine :-

            o  scale 1 / 10
            o  4 heads each 3 torches for steel up to 100 mm. thickness .
